Shielded flame retardant control cable ZC-KVVP 14*1.5 0.45/0.75KV
ZC-KVVP-Copper core PVC insulated PVC textile shielded flame retardant control cable
Flame retardant control cable
Flame-retardant control cable is mainly suitable for use in industrial and mining enterprises, energy and transportation sectors, for AC rated voltage 450/750 volts below the control, proximity and protection of the line and so on. It is suitable for use in industrial and mining enterprises, energy and transportation sectors, for control, proximity and protection lines below 450/750 volts AC rated voltage.
The product implementation standard: GB988412.1-88, GB988412.2-88
Use characteristics Rated voltage: U0/U is 450/750V.
Conductor core long-term operating temperature of 70 ℃, 90 ℃ two, cable laying temperature of not less than 0 ℃.
The recommended permissible bending radius of the cable is as follows: unarmored cable, should be not less than 6 times the outer diameter of the cable; armored or copper tape shielded cable, should be not less than 12 times the outer diameter of the cable; shielded flexible cable, not less than 6 times the outer diameter of the cable.
Fire-resistant: NH, steel tape armored: 22, steel wire armored: 32
Flame retardant grade: ZA (Class A flame retardant), ZB (Class B flame retardant), ZC (Class C flame retardant), ZR (flame retardant)
Shielding options: P copper wire, P1 tinned, P2 copper tape, P3 aluminum foil
Conductors such as soft structure plus R
Flame retardant control cable model and name:
ZCKVV-Copper core PVC insulated PVC sheathed flame retardant control cable.
ZCKVVP3-Copper core PVC insulated PVC sheathed aluminum foil flame retardant shielded control cable.
ZCKVV22 -Copper core PVC insulated PVC sheathed steel tape armored flame retardant control cable.
ZCKVVRP - Copper core PVC insulated PVC sheathed braided shielded flame retardant control flexible cable.
ZCKVVP2 - Copper core PVC insulated PVC sheathed copper tape shielded flame retardant control cable.
ZCKVVP-Copper core PVC insulated PVC textile copper wire shielded flame retardant control cable.
ZCKVVR-copper core PVC insulated PVC sheathed flame retardant control flexible cable.
ZCKVV32 -Copper core PVC insulated PVC sheathed fine steel wire armored flame retardant control cable.
