Name: ZC-KVVP2-22 13*1.5 0.45/0.75KV copper core PVC insulated PVC sheathed steel tape armored copper tape shielded flame retardant control cable
Introduction
Product Standard
This product is manufactured in accordance with GB9330-2008 Plastic Insulated Control Cables, IEC60227 PVC Insulated Cables with Rated Voltage 450/750V and Below, and IEC60502 Extruded Insulated Power Cables and Accessories with Rated Voltage 1-30kV.
Scope of application PVC insulated PVC sheathed control cables are suitable for wiring of control, signaling, protection and measurement systems with rated voltage 450/750V and below.
Explanation
1、Industrial frequency rated voltage Uo/U is 450/750V.
2、The permissible long-term maximum working temperature of the cable conductor is 70℃.
3、The ambient temperature should be not less than 0℃ when the cable is laid, and the cable should be preheated if the ambient temperature is lower than 0℃.
4、The recommended permissible bending radius of the cable is as follows:
5、No armored cable, should be not less than 6 times the outer diameter of the cable;
6, armored or copper tape shielded cable, should be not less than 12 times the outer diameter of the cable;
7. Shielded flexible cables, shall be not less than 6 times the outer diameter of the cable.
8. fire resistance: NH, steel tape armored: 22, steel wire armored: 32
9. Flame retardant grade: ZA (Class A flame retardant), ZB (Class B flame retardant), ZC (Class C flame retardant), ZR (flame retardant).
10. Shielding options: P copper wire, P1 tinned, P2 copper tape, P3 aluminum foil.
11. Conductor such as soft structure plus R
Use
1、ZC-KVVP2-22 copper core PVC insulated PVC sheathed steel tape armored copper tape shielded flame retardant control cable 450/750 2-37 0.75-10 laying in indoor, cable trench, pipeline and other requirements of anti-interference fixed occasions
2、KVV copper core PVC insulated PVC sheathed cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid in indoor, cable trench, pipeline and other fixed occasions
3、KVV22 Copper core PVC insulated PVC sheathed steel armored cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid indoors, cable trenches, pipelines and other fixed occasions to withstand large mechanical external forces.
4、KVVP flame retardant copper core PVC insulated PVC sheathed cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid in indoor, cable trench, pipeline and other fixed occasions requiring shielding
5、KVVP22 copper core PVC insulated PVC sheathed steel tape armored copper wire shielded control cable 450/750 2-37 0.75-10 laying in indoor, cable trench, pipeline and other requirements of anti-interference fixed occasions
6、KVVR Copper core PVC insulated PVC sheathed control flexible cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid indoors, mobile requirements of the occasion
7、 KVVRP Copper core PVC insulated PVC sheathed braided shielded control flexible cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid indoors, occasions with mobile shielding requirements
8、ZCKVV flame retardant copper core PVC insulated PVC sheathed zckvv cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid in indoor, cable trench, pipeline and other requirements of flame retardant fixed occasions
9、ZCKVV22 Copper core PVC insulated PVC sheathed braided steel tape armored zckvv22 cable 450/750 4-37 0.75-10 section, laid in indoor, cable trench, pipeline direct burial, etc. can withstand the larger mechanical external forces have flame retardant requirements of the fixed occasions
10、ZRKVVP Copper core PVC insulated PVC sheath braided shielded zrkvvp cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid in indoor, cable trench, pipeline and other requirements of shielding, flame retardant fixed occasions
11、ZCKVVR Copper core PVC insulated PVC sheathed braided zrkvvr cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid in indoor, mobile and flame retardant requirements of the occasion.
12、ZCKVVRP Copper-core PVC-insulated PVC-sheathed braided shielded zrkvvrp cable 450/750 V, 4-37 cores, 0.75-10 cross-section, laid indoors, with mobile shielding and flame retardant requirements.
