Scope of application
This product is suitable for metallurgy, petroleum, chemical industry and power plants and other industrial and mining enterprises, in high temperature conditions and harsh environments (such as acid, alkali, oil and water at low temperatures) as a variety of electrical appliances, instrumentation and automated devices of the connecting line for the AC rated voltage of 450/750 volts and the following control, monitoring and protection circuits installed under the circumstances.
Model and Name:
| serial number | model number | name (of a thing) |
| 1 | KFF | Fluoroplastic insulated and sheathed control cables |
| 2 | KFFP | Fluoroplastic insulated and sheathed shielded control cables |
| 3 | KFFR | Fluoroplastic insulated and sheathed control flexible cables |
| 4 | KFFRP | Fluoroplastic insulated and sheathed shielded control flexible cables |
| 5 | KFV | Fluoroplastic insulated PVC sheathed control cable |
| 6 | KFVP | Fluoroplastic insulated PVC sheathed shielded control cable |
| 7 | KFVR | Fluoroplastic insulated PVC sheathed control flexible cable |
| 8 | KFVRP | Fluoroplastic Insulated PVC Sheathed Shielded Control Flexible Cable |
| 9 | KFV22 | Fluoroplastic insulated PVC sheathed steel tape armored control cable |
| 10 | KFVP22 | Fluoroplastic insulated PVC sheathed steel tape armored shielded control cable |
| 11 | KFVR22 | Fluoroplastic insulated PVC sheathed steel tape armored control flexible cable |
| 12 | KFVRP22 | Fluoroplastic insulated PVC sheathed steel tape armored shielded control flexible cable |
| 13 | KFFV22 | Fluoroplastic insulation and inner sheath PVC outer sheath steel tape armored control cable |
| 14 | KFFRV22 | Fluoroplastic insulation and inner sheath PVC outer sheath steel tape armored control flexible cable |
Use characteristics and technical parameters:
1、Rated voltage: AC Uo / U;450/750V
2、Operating temperature： -60～+260℃
3, insulation resistance (20 ℃) not less than 50MΩ-km
4, conductor core DC resistance (20 ℃) in line with the provisions of GB3956-97
5、Unarmored cable allows bending radius of not less than 6 times the outer diameter of the cable, armored cable allows bending radius of not less than 12 times the outer diameter of the cable.
6. Minimum installation and laying temperature: -25℃.
7. Fire resistance: NH, steel tape armored: 22, steel wire armored: 32
8. Flame retardant grade: ZA (Class A flame retardant), ZB (Class B flame retardant), ZC (Class C flame retardant), ZR (flame retardant)
9. Shielding options: P copper wire, P1 tin-plated, P2 copper tape, P3 aluminum foil
Specification size reference data:
| serial number | Nominal cross-section | Conductor core specifications | Conductor core specifications | Number of cable cores | ||
|
1，2，5，6，9，10，13 |
3，4，7，8，11，12，14 |
1～4 |
5～8 |
9～14 |
||
|
1 2 3 4 5 |
0.2 0.5 0.75 1.0 1.5 2.5 |
1/0.52 1/0.80 1/1.0 1/1.13 1/1.38 1/1.76 |
7/0.20 16/0.20 19/0.23 24/0.20 19/0.26 32/0.20 19/0.32 30/0.25 49/0.26 |
2～44 2～30 2～19 2～16 2～14 2～8 |
2～61 |
7～37 7～37 7～37 4～37 |
Note: Our company can according to customer site requirements: R & D customized production of various types and specifications of cable.
